Mine Underground Anchor Rig



Raws li ib qho tseem ceeb tsis tseem ceeb ntawm - lub hom phiaj tseem ceeb engineering cov cuab yeej hauv kev tsim kho vaj tse, geotechnical engineering drilling rigs yog cov cuab yeej tshwj xeeb rau kev tshawb nrhiav geological, geotechnical foundation tsim, thiab geological kev puas tsuaj. Lawv tuaj yeem ua tau yooj yim nrog cov cuab yeej sib txawv xws li cov tub ntxhais xyaum xyaum, auger xyaum, nqes - lub - qhov rauj, thiab cov cuab yeej ua haujlwm raws li kev xav tau tiag tiag, txhawb ntau yam kev siv drilling xws li kev cuam tshuam kev sib hloov, siab zoo li qub, thiab kev xa mus rau pem hauv ntej / rov qab. Lawv tuaj yeem ua haujlwm tau zoo txawm tias nyob hauv roob lossis nqaim, txwv tsis pub hauv nroog: lawv tuaj yeem ua tiav qhov kev tshawb fawb tseem ceeb thiab hauv - qhov kev sim, kom tau txais cov av tsis muaj teeb meem thiab cov qauv pob zeb thiab cov qauv hydrogeological los muab cov ntaub ntawv pov thawj kev txhawb nqa rau engineering tsim; lawv kuj tuaj yeem ua tiav ntau lub qhov- tsim cov haujlwm xws li lub hauv paus qhov chaw txhawb nqa thauj tog rau nkoj bolts / cables, cam khwb cia- hauv- qhov chaw piles, dewatering qhov dej, txoj kab nqes anchoring qhov, thiab kev tswj kev puas tsuaj grouting qhov. Cov khoom siv yog yoog tau rau feem ntau cov geological tej yam kev mob, thiab yuav drilled zoo nyob rau hauv cov av mos, xuab zeb, gravel thiab me ntsis weathered hard pob zeb. Tam sim no, Mine underground anchor rig tau siv dav hauv ntau qhov kev lag luam xws li kev tsim vaj tsev, kev thauj mus los hauv nroog, kev txuag dej thiab kev siv hluav taws xob, kev tsuas, kev loj hlob hauv av qis thiab kev tiv thaiv geological. Nws yog ib qho tseem ceeb ntawm cov cuab yeej siv los txo cov nqi thiab txhim kho kev ua haujlwm hauv engineering.







Geotechnical engineering drilling rig
Qauv	TIAB SA 1095
Rated zog (kW)	55+37+2.2
Kab ntsig Band Model No.	LG-101
Tramming Tsav	Ob - ceev
Tramming ceev (km / h)	1.8/3.3
Hauv av siab (N / cm2)	5.5
Gradeability ( degree)	20
Rotary taub hau	Kev sib hloov nrog percussion
Kev sib hloov ntawm cov iav qis (r / min)	0-35
Kev sib hloov ntawm cov iav siab (r / min)	0-110
Torque ntau ntawm cov iav siab (Nm)	5000
Torque ntau ntawm cov iav qis (Nm)	10000
Ua haujlwm cuam tshuam (N * m)	750
Percussion zaus (min1)	1100
Mast	Swb extention mast
Feed stroke (mm)	900-1900
Pub zog (kN)	63
Retraction quab yuam (kN)	95
Pub tus nqi (m / min)	0-9.2-9.2 0-28.5
Retraction tus nqi (m / min)	0-6.1=-6.1 0-18.5
Pub Qauv	Hydraulic lub tog raj kheej
Clamp ntau yam (mm)	60-210
Max.clamp quab yuam (KN)	310
Kev thauj mus los dimension ntawm laum rig (mm)	3353x1200x2300
Lub zog pob qhov ntev (mm)	3200x1200x2000
Qhov hnyav (T)	5.5+2.4







• Geological Core Sampling: Tau txais cov qauv qauv yam tsis muaj kev cuam tshuam cov av lossis cov pob zeb.
• Hauv -Situ Geotechnical Testing: Ntsuas av thiab dej hauv av ncaj qha rau ntawm -site.
• Foundation Anchor Hole Drilling: Ua kom yooj yim rau kev teeb tsa cov thauj tog rau nkoj lossis pob zeb bolts rau khaws cov phab ntsa thiab cov qauv.
• Bored Pile thiab Drainage Well Construction: Ua kom muaj kev tsim kho ntawm cov hauv paus sib sib zog nqus thiab kev tswj dej hauv av.
• Slope Stabilization Drilling: Drills qhov rau grouting los txhawb kev tiv thaiv kev puas tsuaj thiab kev txhim kho txoj kab nqes.
• Ntau txoj hauv kev Drilling: Tso cai rau kev xaiv cov txheej txheem drilling uas tsim nyog (xws li kev sib hloov-percussive, zoo li qub, lossis rov qab ncig) raws li cov xwm txheej geological thiab kev ua haujlwm.





• Ntau- ua haujlwm tau zoo, txo qis tus nqi yuav khoom: Ib chav tsev tuaj yeem hloov tau peb hom khoom siv: kev tshawb nrhiav qhov drilling rigs, thauj tog rau nkoj drilling rigs, thiab me me core drilling rigs. Cov nqi yuav khoom raug txo los ntawm ntau dua 40% piv rau kev yuav khoom ntau lub koom haum tshwj xeeb, tsis txhob ua haujlwm tsis muaj zog thiab khib nyiab ua qauv. Txawm tias me me thiab micro- pawg engineering loj tuaj yeem them taus.
• Adaptable rau tag nrho cov geological formations, tsis muaj kev tsim kho qhov muag tsis pom kev: Nws muaj peev xwm ua tau zoo xyaum los ntawm cov av mos, xuab zeb, gravel, thiab nruab nrab huab cua nyuaj pob zeb yam tsis tas yuav hloov cov cuab yeej vim muaj kev hloov hauv geological formations. Nws tuaj yeem raug xa ncaj qha ntawm cov haujlwm, nce kev siv cov cuab yeej siv los ntawm 60%.
• Kev hloov tau yooj yim rau qhov chaw nqaim, tsis tshua muaj kev thaiv: Lub tshuab tag nrho txais cov qauv tsim thiab lub teeb yuag, thiab tuaj yeem muab faib ua peb lub modules, txhua qhov hnyav dua lossis sib npaug li 500kg. Nws tuaj yeem thauj tau manually mus rau thaj chaw roob, hauv qab daus nrog qhov siab txwv ntawm 2.2 meters, thiab nqaim thaj chaw nyob, daws qhov mob ntawm qhov loj drilling rigs tsis tuaj yeem nkag mus rau qhov chaw txwv.
• Tsawg tus nqi tu thiab ruaj khov. Cov khoom tseem ceeb ntawm Mine underground anchor rig yog ua los ntawm hnav- cov ntaub ntawv tiv taus, thiab cov khoom tsis zoo yog tag nrho cov kev lag luam- tus qauv, uas tsis tshua muaj nqi ntawm kev yuav khoom thiab hloov tau yooj yim. Qhov nruab nrab lub sij hawm nruab nrab ntawm kev ua tsis tiav (MTBF) ntawm cov cuab yeej siv ntau tshaj 1,500 teev, uas txo tus nqi txij nkawm los ntawm 35% piv nrog cov khoom siv zoo sib xws.
